| Locator | Hist Soc - HS-C08154 | Type | Drawing | Doc Number | 1468b | |
|---|---|---|---|---|---|---|
| Description | Plan of Foundation for 42Ft Track Scale with Dead Rail Attachment | |||||
| Date | Revision Date | |||||
| Author | Fairbanks & Co. | Accession | ||||
|
||
Size: 21in x 6in (53cm x 16cm) |
| Related | 1468 | Hist Soc - HS-CC04351 | Plan of foundation for 42ft scale with dead-rail, Dead-rail 16" from scale Coe - "Scale - 42-ft - bill of timer - plan of foundation" |
| Related | 1468 | Hist Soc - HS-C08157 | Plan of Foundation for 42Ft Scale with dead rail Center of Scale Track will come in Center of 7'2"Space Dead Rail 16' away from Scale Track for Suffolk 11-29-1897 |
| Related | 1468c | Hist Soc - HS-C08155 | Plan of Foundation for 42Ft Scale with dead Rail Center of Scale Track will come in Center of 7'2"Space Dead Rail 16' futher away from weight Box |
| Child | 1468b | Hist Soc - HS-A10940 | Bill of Timber for Fairbanks 42', 4 Sections, 4 ft 8-1/2" Gauge Iron Frame RR Track Scale |
| Structure | Scales - Various |
| Company | N&W RR - Norfolk & Western Railroad |
