| Locator | Hist Soc - HS-C08157 | Type | Drawing | Doc Number | 1468 | |
|---|---|---|---|---|---|---|
| Description | Plan of Foundation for 42Ft Scale with dead rail Center of Scale Track will come in Center of 7'2"Space Dead Rail 16' away from Scale Track | |||||
| Notes | for Suffolk 11-29-1897 | |||||
| Date | 12/11/1891 | Revision Date | ||||
| Author | N&W RR - Kenova WV | Accession | ||||
|
||
Size: 23in x 9in (58cm x 24cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Kenova | WV |
| Suffolk | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Scales | Various |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W Rwy | Scioto | ||
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | 1468c | Hist Soc - HS-C08155 | Plan of Foundation for 42Ft Scale with dead Rail Center of Scale Track will come in Center of 7'2"Space Dead Rail 16' futher away from weight Box |
| Related | 1468b | Hist Soc - HS-C08154 | Plan of Foundation for 42Ft Track Scale with Dead Rail Attachment |
| Child | 1468 | Hist Soc - HS-A10939 | Bill of Timber for 42 ft Track Scale with Dead Rail Attachment |
