| Locator | Hist Soc - HS-C08155 | Type | Drawing | Doc Number | 1468c | |
|---|---|---|---|---|---|---|
| Description | Plan of Foundation for 42Ft Scale with dead Rail Center of Scale Track will come in Center of 7'2"Space Dead Rail 16' futher away from weight Box | |||||
| Date | Revision Date | |||||
| Author | Fairbanks & Co. | Accession | ||||
|
||
Size: 20in x 6in (52cm x 16cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Scales | Various |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | 1468b | Hist Soc - HS-C08154 | Plan of Foundation for 42Ft Track Scale with Dead Rail Attachment |
| Related | 1468 | Hist Soc - HS-C08157 | Plan of Foundation for 42Ft Scale with dead rail Center of Scale Track will come in Center of 7'2"Space Dead Rail 16' away from Scale Track |
| Child | 1468c | Hist Soc - HS-A10941 | Bill of Timber for 42 ft Track Scale with Dead Rail Attachment |
