Locator Hist Soc - HS-W00450 Type Drawing Doc Number 2511
Description Washington Branch - showing location on Pinnet's Run and connection with PRR at Long Bridge; also shows B&O Location on Pinnet's Run
Notes Title from BV-E00001
Date 01/16/1893 Revision Date
Author N&W RR - Engr Maint of Way Accession 2009.001 : NS Corp/Va Tech Collection

Washington Branch - showing location on Pinnet's Run and connection with PRR at Long Bridge; also shows B&O Location on Pinnet's Run

Size: 11.05ft x 38in (3.4m x 96cm)

Parent   Bound Volume - BV-E00001 Copy, Index of Maps, W.W. Coe
 Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank.
Related 2511 Hist Soc - HS-G10743 N&W RR Washington Branch, Map showing short preliminary lines, near Washington DC
 Scale 1"=400'.
