| Locator | Hist Soc - HS-G10743 | Type | Drawing | Doc Number | 2511 | |
|---|---|---|---|---|---|---|
| Description | N&W RR Washington Branch, Map showing short preliminary lines, near Washington DC | |||||
| Notes | Scale 1"=400'. | |||||
| Date | 03/14/1891 | Revision Date | ||||
| Author | N&W RR - Eng in Charge | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 60in x 42in (153cm x 106cm) |
| Related | Hist Soc - HS-R00054 | N&W RR Washington Branch, Profile showing short preliminary lines near Washington DC Lines E, G, K and N. |
|
| Related | Hist Soc - HS-R00053 | N&W RR Washington Branch, Profile showing short preliminary lines near Washington DC Lines C, D, F |
|
| Related | 2511 | Hist Soc - HS-W00450 | Washington Branch - showing location on Pinnet's Run and connection with PRR at Long Bridge; also shows B&O Location on Pinnet's Run Title from BV-E00001 |
| Related | 2510 | Hist Soc - HS-W10110 | N&W RR Washington Branch, Pimmitt Run Location. Survey of proposed line from Vienna down Pimmitt Run to Potomac River, then along river into Washington. Scale 1"=400'. D.W. Flickwir, General Supt., F.B. Morss., Engineer in Charge. |
| City | Washington - DC |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Maryland&Washington |
