| Locator | Hist Soc - HS-K10648 | Type | Drawing | Doc Number | 1245 | |
|---|---|---|---|---|---|---|
| Description | Cape Fear & Yadkin Valley Railway, Map of location from Mt Airy to Virginia line, Connecting with Norfolk & Western preliminary on Naked Run | |||||
| Date | 11/01/1888 | Revision Date | ||||
| Author | Cape Fear & Yadkin Valley Ry | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 66in x 15in (168cm x 37cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | Hist Soc - HS-D10553 | Norfolk and Western RR, New River Cripple Creek, Mineral Territory Encapsulated, color. Shows from Pulaski with proposed connection to Cape Fear & Yankin Valley RR with loop |
|
| Related | 1018 | Hist Soc - HS-K10036 | Map of location of Cape Fear & Yadkin Valley from Mt. Airy to N&W Connection at VA state line. See HS-E10336 for map showing proposed N&W extension of NC branch to meet CF&YV at state line. |
| Related | Hist Soc - HS-E10549 | N&W RR, Map Showing Surveys made to Develop the Country between Cripple Creek Extension and Cape Fear & Yadkin Valley RR Showing also Copper Ore Leads, to accompany Report of June 8th 1889. Scale 1"=1 mile. |
|
| Related | Digital Scan - DS00366 | Sketch of Locations for Proposed Railroad from Little Reed Island Junction to Mount Airy, NC From NS archives folder 2009.NW.1.105, North Carolina Extension Correspondence, reports, etc. |
|
| Related | Hist Soc - HS-C11001 | Sketch of Country between Ivanhoe and Mt Airy Scale 1"=2 miles. Shows two routes between Ivanhoe and Mt Airy with connection with CF&YV RR. One with loop around "Wheeler's Knob" and the other following New River to Lowes Gap. |
|
| Related | 1428 | Hist Soc - HS-H00867 | N&W North Carolina Extension, Map Showing Proposed Terminal Facilities of hte N&W RR at the Virginia and North Carolina State Line together with the distribution of land between tne N&W RR, Virginia Company and the Cape Fear and Yadkin Valley RR Scale 1"=200' |
| Company | Cape Fear & Yadkin Valley |
