| Locator | Hist Soc - HS-D05428 | Type | Drawing | Doc Number | 1418 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Details of Bulkhead for Warehouse Pier at Lambert's Point Va. | |||||
| Notes | Scale 1 1/2" = 1' | |||||
| Date | 12/14/1889 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 29in x 22in (74cm x 55cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Lamberts Point | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Warehouse | |
| Pier | |
| Pier | Warehouse |
| Building | Warehouse |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| People Indexes | ||
|---|---|---|
| Job Title | First Name | Last Name |
| Chief Engr | W.W. | Coe |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
| Related | 1418 | Hist Soc - HS-CC03198 | N&W RR, Front Elevation of Addition to Warehouse at Lambert's Point |
