| Locator | Hist Soc - HS-D05426 | Type | Drawing | Doc Number | 1418 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Suggestion for Water Pipes for Fire purposes at Lamberts Point Warehouse | |||||
| Notes | Scale 1" = 40' | |||||
| Date | 08/18/1890 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 28in x 25in (70cm x 62cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Lamberts Point | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Warehouse | |
| Pier | |
| Pier | Warehouse |
| Building | Warehouse |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
| Related | 1418 | Hist Soc - HS-CC03198 | N&W RR, Front Elevation of Addition to Warehouse at Lambert's Point |
