| Locator | Hist Soc - HS-CC03200 | Type | Drawing | Doc Number | 1418 | |
|---|---|---|---|---|---|---|
| Description | Plan of Bulkhead on the South Side of Coal Pier at Lambert's Point | |||||
| Notes | Scale 1"=2' | |||||
| Date | 02/19/1886 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 26in x 16in (66cm x 40cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 1418 | Hist Soc - HS-CC03198 | N&W RR, Front Elevation of Addition to Warehouse at Lambert's Point Scale 1/8" = 1' |
| City | Lamberts Point - VA |
| Structure | Pier - Coal |
| Structure | Pier |
| Company | N&W RR - Norfolk & Western Railroad |
