| Locator | Hist Soc - HS-D05276 | Type | Drawing | Doc Number | 1710 | |
|---|---|---|---|---|---|---|
| Description | N&W RR Ohio Extension, Siding to Proposed Mines - Sycamore Branch | |||||
| Notes | Scale 1"=100', No Date, Sheet 3 | |||||
| Date | Revision Date | |||||
| Author | N&W RR - Eng in Charge | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 24in x 19in (62cm x 49cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Siding |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W RR | Ohio Extension | ||
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | 1710 | Hist Soc - HS-D05275 | N&W RR Ohio Extension, Siding to Proposed Mines - Sycamore Branch |
| Related | 1710 | Hist Soc - HS-D05274 | N&W RR Ohio Extension, Siding to Proposed Mines - Sycamore Branch |
| Related | 1710 | Hist Soc - HS-G11013 | N&W RR Ohio Extension, Siding to Proposed Mines on Sycamore Branch, Dunlow WV |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
