| Locator | Hist Soc - HS-D05275 | Type | Drawing | Doc Number | 1710 | |
|---|---|---|---|---|---|---|
| Description | N&W RR Ohio Extension, Siding to Proposed Mines - Sycamore Branch | |||||
| Notes | Scale 1"=100', No Date, Sheet 2 | |||||
| Date | Revision Date | |||||
| Author | N&W RR - Eng in Charge | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 24in x 19in (62cm x 49cm) |
| Related | 1710 | Hist Soc - HS-D05274 | N&W RR Ohio Extension, Siding to Proposed Mines - Sycamore Branch Scale 1"=100', No Date |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 1710 | Hist Soc - HS-G11013 | N&W RR Ohio Extension, Siding to Proposed Mines on Sycamore Branch, Dunlow WV |
| Related | 1710 | Hist Soc - HS-D05276 | N&W RR Ohio Extension, Siding to Proposed Mines - Sycamore Branch Scale 1"=100', No Date, Sheet 3 |
| Structure | Track - Siding |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Ohio Extension |
