| Locator | Hollinger - Hol-00404.53 | Type | Drawing | Doc Number | 499 | |
|---|---|---|---|---|---|---|
| Description | Proposed Plan for Flat Top Yard | |||||
| Notes | Three pages, "Cross Sections at New Coal Yard", New River Division | |||||
| Date | 04/08/1886 | Revision Date | ||||
| Author | Accession | 2009.001 : NS Corp/Va Tech Collection | ||||
|
|
|
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 499 | Hist Soc - HS-G10935 | Proposed Plan for Flat Top Yard Scale 1"=40', In pencil "Bluestone yard", No date, Coe books lists it as "Bluestone Yard" |
| City | Yards - VA |
| City | Yards - WV |
| Structure | Yard |
| Company | N&W RR - Norfolk & Western Railroad |
