| Locator | Hist Soc - HS-G10935 | Type | Drawing | Doc Number | 499 | |
|---|---|---|---|---|---|---|
| Description | Proposed Plan for Flat Top Yard | |||||
| Notes | Scale 1"=40', In pencil "Bluestone yard", No date, Coe books lists it as "Bluestone Yard" | |||||
| Date | Revision Date | |||||
| Author | Accession | 2009.001 : NS Corp/Va Tech Collection | ||||
|
||
Size: 64in x 19in (161cm x 48cm) |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 499 | Hollinger - Hol-00404.53 | Proposed Plan for Flat Top Yard Three pages, "Cross Sections at New Coal Yard", New River Division |
| Child | 499 | Hist Soc - HS-D04762 | Untitled, Continutation of HS-G10935 |
| City | Yards - VA |
| City | Yards - WV |
| Structure | Yard |
| Company | N&W RR - Norfolk & Western Railroad |
