| Locator | Hist Soc - HS-D06825 | Type | Drawing | Doc Number | 1618 | |
|---|---|---|---|---|---|---|
| Description | Map of Surveys from Tip Top Station to Col. May's Iron Mine | |||||
| Notes | Coe books shows "Tip Top Va - projected lines to the mines of the Graham Furnace Co" | |||||
| Date | 01/21/1890 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 23in x 22in (58cm x 56cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 1618 | Hist Soc - HS-T00253 | Tip Top Branch, Clinch Valley Division, N&W RR Coe books shows "Tip Top Va - projected lines to the mines of the Graham Furnace Co" |
| Related | 1618 | Hist Soc - HS-G01778 | Tip Top Branch, Clinch Valley Division, N&W RR Coe books shows "Tip Top Va - projected lines to the mines of the Graham Furnace Co" |
| City | Tip Top - VA |
| Structure | Track - Siding |
| Company | N&W RR - Norfolk & Western Railroad |
| Company | Graham Furnace Co. |
| Division | N&W Rwy - Pocahontas - Clinch Valley District |
