| Locator | Hist Soc - HS-B24922 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Typical Design for Coal Trestle with Welded Steel Hopper, Wood Bents and Stringers, 11'-0" span | |||||
| Notes | Sheet 52-C. Includes cost estimation table. | |||||
| Date | 09/19/1946 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
||
Size: 15in x 6in (37cm x 15cm) |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Related | N-7500 | Hist Soc - HS-B24921 | Typical Design for Coal Trestle with I-Beam Stringers & Concrete Piers, spans 20'-0" center to center. Sheet 52-B. |
| Related | N-7500 | Hist Soc - HS-A08773 | Typical Design for Coal Trestle with I-Beam Stringers & Concrete Piers, spans 15'0" center to center. Sheet 52-A. |
| Structure | Coal - Trestle |
| Company Docs | N&W Rwy - Cost Estimation Tables |
