| Locator | Hist Soc - HS-B24945 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | N&W Ry. Coopers Moment Equivalent for Various Locomotives and Norfolk & Western Specifications | |||||
| Notes | Sheet 118. G1, K3, M1, M2c, W2, Y2, Y3a, Y4, Y5, Z1a, Z1b., spec of 1899, 1903, 1911. Also 22,000 Gallon Tank, 70 Ton Car, | |||||
| Date | 05/23/1932 | Revision Date | 10/26/1942 | |||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
|
|
Size: 16in x 9in (39cm x 23cm) |
| Rolling Stock Indexes | |||||
|---|---|---|---|---|---|
| Category | Type | Road Name | Class | Builder | Other |
| Locomotive | Steam | N&W Rwy | G1 | 2-8-0 | |
| Locomotive | Steam | N&W Rwy | K3 | Roanoke Shops | 4-8-2 |
| Locomotive | Steam | N&W Rwy | M1 | 4-8-0 | |
| Locomotive | Steam | N&W Rwy | M2c | Roanoke Shops | 4-8-0 |
| Locomotive | Steam | N&W Rwy | W2 | 2-8-0 | |
| Locomotive | Steam | N&W Rwy | Y2 | 2-8-8-2 | |
| Locomotive | Steam | N&W Rwy | Y3a | 2-8-8-2 | |
| Locomotive | Steam | N&W Rwy | Y4 | Alco-Richmond | 2-8-8-2 |
| Locomotive | Steam | N&W Rwy | Y5 | Roanoke Shops | 2-8-8-2 |
| Locomotive | Steam | N&W Rwy | Z1a | 2-6-6-2 | |
| Locomotive | Steam | N&W Rwy | Z1b | 2-6-6-2 | |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 |
| Related | N-7500 | Hist Soc - HS-B24946 | N&W Ry. Moment Table for Class Z1b Engine, 16,0000 Gallon Tender, 23 Tons Coal |
| Related | N-7500 | Hist Soc - HS-B24947 | N&W Ry. Moment Table for Class A Locomotive, 22,0000 Gallons Water, 26 Tons Coal |
| Related | N-7500 | Hist Soc - HS-B24948 | N&W Ry. Moment Table for Class J Locomotive with Booster, 22,0000 Gallons Water, 26 Tons Coal |
| Related | N-7500 | Hist Soc - HS-B24949 | N&W Ry. Moment Table for Class Y5 Engine 2-8-8-2 Heavy Mallet, 22,0000 Gallons Water, 26 Tons Coal |
| Related | N-7500 | Hist Soc - HS-C06702 | N&W Ry. Coopers Moment Equivalent for Derricks, Norfolk & Western Specifications |
| Related | N-7500 | Hist Soc - HS-C06700 | N&W Ry. Coopers Moment Equivalent for Locomotives, Norfolk & Western Specifications |
| Related | N-7500 | Hist Soc - HS-C06701 | N&W Ry. Coopers Moment Equivalent for Cars, Norfolk & Western Specifications |
| Related | N-7500 | Hist Soc - HS-C06703 | N&W Ry. Coopers Moment Equivalent for ______, Norfolk & Western Specifications |
