| Locator | Hist Soc - HS-C06701 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | N&W Ry. Coopers Moment Equivalent for Cars, Norfolk & Western Specifications | |||||
| Notes | Sheet 118-2. H2, H2a, H11, H11a, H11b, H13, H15, HC14. | |||||
| Date | 08/19/1965 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
|
|
Size: 19in x 9in (47cm x 23cm) |
| Related | N-7500 | Hist Soc - HS-C06700 | N&W Ry. Coopers Moment Equivalent for Locomotives, Norfolk & Western Specifications Sheet 118-1. Y5, GP9, RS11, C628, GP30. |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Related | N-7500 | Hist Soc - HS-C06702 | N&W Ry. Coopers Moment Equivalent for Derricks, Norfolk & Western Specifications Sheet 118-3. 150 Ton, 200 Ton and 250 Ton Derricks. |
| Related | N-7500 | Hist Soc - HS-C06703 | N&W Ry. Coopers Moment Equivalent for ______, Norfolk & Western Specifications Sheet 118-4. Comparison of 1899, 1903, 1911 |
| Related | N-7500 | Hist Soc - HS-B24945 | N&W Ry. Coopers Moment Equivalent for Various Locomotives and Norfolk & Western Specifications Sheet 118. G1, K3, M1, M2c, W2, Y2, Y3a, Y4, Y5, Z1a, Z1b., spec of 1899, 1903, 1911. Also 22,000 Gallon Tank, 70 Ton Car, |
| Related | N-7500 | Hist Soc - HS-B24946 | N&W Ry. Moment Table for Class Z1b Engine, 16,0000 Gallon Tender, 23 Tons Coal Sheet 118-A. |
| Related | N-7500 | Hist Soc - HS-B24947 | N&W Ry. Moment Table for Class A Locomotive, 22,0000 Gallons Water, 26 Tons Coal Sheet 118-B. |
| Related | N-7500 | Hist Soc - HS-B24948 | N&W Ry. Moment Table for Class J Locomotive with Booster, 22,0000 Gallons Water, 26 Tons Coal Sheet 118-C. |
| Related | N-7500 | Hist Soc - HS-B24949 | N&W Ry. Moment Table for Class Y5 Engine 2-8-8-2 Heavy Mallet, 22,0000 Gallons Water, 26 Tons Coal Sheet 118-D. |
| Rolling Stock | N&W Rwy - Freight - Hopper - H2a |
| Rolling Stock | N&W Rwy - Freight - Hopper - Roanoke Shops - H11 |
| Rolling Stock | N&W Rwy - Freight - Hopper - Roanoke Shops - H11a |
| Rolling Stock | N&W Rwy - Freight - Hopper - Roanoke Shops - H11b |
| Rolling Stock | N&W Rwy - Freight - Hopper - Roanoke Shops - H13 |
| Rolling Stock | N&W Rwy - Freight - Covered Hopper - Magor - HC14 |
| Rolling Stock | N&W Rwy - Freight - Hopper - H15 |
| Rolling Stock | N&W Rwy - Freight - Hopper - H2 |
| Company | N&W Rwy - Norfolk & Western Railway |
