| Locator | Hist Soc - HS-D05583 | Type | Drawing | Doc Number | 416 | |
|---|---|---|---|---|---|---|
| Description | Iron Work, 60ft Canal Draw Bridge for Public Road from Brambleton to N&W Station at Norfolk, VA | |||||
| Notes | Title from W.W. Coe index of Maps: "Brambleton Canal Highway Bridge Norfolk- Details of Iron Work 60ft ??pan" | |||||
| Date | 10/24/1885 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 36in x 23in (91cm x 58cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| City | Norfolk - VA |
| Structure | Bridge - Drawbridge |
| Structure | Bridge - Highway |
