| Locator | Hist Soc - HS-E02264 | Type | Drawing | Doc Number | 2216 | |
|---|---|---|---|---|---|---|
| Description | Wrights Cr. Crossing, Sta. 129 | |||||
| Notes | Scale 1/2" = 1', Span 18' 6", Bridge #1303 by Coe Book | |||||
| Date | 08/16/1887 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 38in x 19in (96cm x 48cm) |
| Related | 2216 | Hist Soc - HS-B13260 | Map and Profile, Wrights Cr. Crossing, Sta. 129 Penciled in as "No 2" |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 2216 | Hist Soc - HS-E02263 | Wrights Cr. Crossing, Sta. 129 Scale 1/2" = 1', Span 18' 6", Bridge #1303 by Coe Book |
| Structure | Bridge |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W Rwy - Pocahontas - Clinch Valley District |
