| Locator | Hist Soc - HS-C05527 | Type | Drawing | Doc Number | 2291 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Clinch Valley Division, General Plan for Trestle Bridges, Big Creek Branch | |||||
| Notes | Scale 1"=4', No date | |||||
| Date | Revision Date | |||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 23in x 10in (60cm x 25cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 2291 | Hist Soc - HS-D05429 | N&W RR Clinch Valley Div., Big Creek Branch, General Plan for Trestle Bridges on Skew Scale 1"=4' |
| Structure | Bridge |
| Structure | Bridge - Trestle |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Clinch Valley - Big Creek Branch |
