Locator Hist Soc - HS-C05277 Type Drawing Doc Number 80
Description N&W RR. Suggestion for Bulkhead to retain dredged material placed back of it. This can be used as anchorage for a bulkhead suitable for deep water to be build 12 feet in front of it when required
Notes Title from W.W. Coe Index of Maps: "Bulkhead - suggestions for; to retain dredged material at Lambert Point"
Date 01/22/1885 Revision Date
Author N&W RR - Office of Chief Engr Accession 2009.001 : NS Corp/Va Tech Collection

N&W RR. Suggestion for Bulkhead to retain dredged material placed back of it. This can be used as anchorage for a bulkhead suitable for deep water to be build 12 feet in front of it when required

Size: 22in x 10in (56cm x 24cm)

Parent   Bound Volume - BV-E00001 Copy, Index of Maps, W.W. Coe
 Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank.
City Lamberts Point - VA
Structure Pier - Bulkhead
Company N&W RR - Norfolk & Western Railroad
