| Locator | Hist Soc - HS-F02994 | Type | Drawing | Doc Number | 431 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Plan of Trestle with 25 ft Center Span over Buddle Creek, Cripple Creek Extension | |||||
| Notes | Scale 3/8" = 1', Bridge #1515 | |||||
| Date | 06/22/1887 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 42in x 16in (108cm x 40cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Bridge | |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W RR | Radford | Cripple Creek Extension | |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
