| Locator | Hist Soc - HS-D05280 | Type | Drawing | Doc Number | 550 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Flat Top Extension, Projected Lines between Bluestone River and Flipping Creek | |||||
| Notes | Scale 1"=1000' | |||||
| Date | 07/23/1886 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 23in x 18in (57cm x 47cm) |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Flat Top Extension |
