| Locator | Hist Soc - HS-H00918 | Type | Drawing | Doc Number | 726 | |
|---|---|---|---|---|---|---|
| Description | Proposed Shed for Cotton and Tobacco to be built on Pier No 1 Norfolk, Framing Plan | |||||
| Notes | Scale 1"=4' | |||||
| Date | 08/05/1887 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 48in x 19in (122cm x 47cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| Structure | Pier |
| Structure | Pier - Warehouse |
| Company | N&W RR - Norfolk & Western Railroad |
