| Locator | Hist Soc - HS-D05198 | Type | Drawing | Doc Number | 1711 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Ohio Extension, Siding to Proposed Mines on Mays Branch | |||||
| Notes | Scale 1"=50', Sheet 2, Coe shows it as "Ohio Extension - 12-Pole on May's Branch" | |||||
| Date | 12/08/1891 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 24in x 19in (62cm x 49cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Siding |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W RR | Ohio Extension | ||
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
| Parent | 1711 | Hist Soc - HS-D05197 | N&W RR, Ohio Extension, Siding to Proposed Mines on Mays Branch |
