| Locator | Hist Soc - HS-D05199 | Type | Drawing | Doc Number | 80 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Plan of Bulkhead at Lamberts Point for Retaining Dredged Material | |||||
| Notes | Scale 1/2" = 1' | |||||
| Date | 10/10/1884 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 35in x 20in (88cm x 51cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Lamberts Point | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Pier | Bulkhead |
| Right of Way | Retaining Wall |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
