| Locator | Hist Soc - HS-CC02706 | Type | Drawing | Doc Number | 2507 | |
|---|---|---|---|---|---|---|
| Description | Washington Branch - Front Royal, VA, Line "Z" | |||||
| Notes | "Happy Creek" | |||||
| Date | 12/01/1890 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 42in x 11in (107cm x 29cm) |
| Related | 2507 | Hist Soc - HS-CC02707 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-CC02708 | Untitled, Washington Branch early survey No date, Appears to be connection with Washington & Alexandria Railroad at "Hydraulic Brick Works", Alexandria Turnpike" |
| Related | 2507 | Hist Soc - HS-CC02709 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-CC02710 | Untitled, Washington Branch early survey, Linden, VA with Virginia Midland shown No date |
| Related | 2507 | Hist Soc - HS-CC02711 | Untitled, Washington Branch early survey, Line with profile No date |
| Related | 2507 | Hist Soc - HS-CC02712 | Untitled, Washington Branch early survey. "Wapping Creek" No date |
| Related | 2507 | Hist Soc - HS-CC02713 | Untitled, Washington Branch early survey. Line P1, "Pimmitts Run" No date, "Langley & Leesburg Turnpike" |
| Related | 2507 | Hist Soc - HS-CC02714 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-CC02715 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-CC02716 | Untitled, Washington Branch early survey, "Line L3", "Wapping road to Front Royal" No date |
| Related | 2507 | Hist Soc - HS-CC02717 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-CC02718 | Untitled, Washington Branch early survey, "Line R4", "Road to Marshall", "Line A12" No date |
| Related | 2507 | Hist Soc - HS-CC02719 | Untitled, Washington Branch early survey, "Road to Five Forks", "Line A12" No date |
| Related | 2507 | Hist Soc - HS-CC02720 | Untitled, Washington Branch early survey, "County Road to Five Forks", "Cromwells Run" No date |
| Related | 2507 | Hist Soc - HS-CC02721 | Untitled, Washington Branch early survey, Profile, "Potomac Boat Club Landing", Plimmill Run, Line P1? No date |
| Related | 2507 | Hist Soc - HS-CC02722 | Untitled, Washington Branch early survey, Profile, Shenandoah River No date |
| Related | 2507 | Hist Soc - HS-K00329 | Untitled, Washington Branch early survey, Plimmitts Run, Line P1 No date, 275' Tunnel |
| Related | 2507 | Hist Soc - HS-K00330 | Untitled, Washington Branch early survey, Plimmitts Run, Line P1, P3, Potomac River No date |
| Related | 2507 | Hist Soc - HS-K00331 | Untitled, Washington Branch early survey, Profile, "Free Bridge", Georgetown, DC (opposite), South end Long Bridge No date, Line P1 |
| Related | 2507 | Hist Soc - HS-K00332 | Untitled, Washington Branch early survey, Goose Creek No date, Between Linden & Markham |
| Related | 2507 | Hist Soc - HS-K00333 | Untitled, Washington Branch early survey, Cromwells Run No date |
| Related | 2507 | Hist Soc - HS-K00334 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-K00335 | Untitled, Washington Branch early survey, Profile, "Pimmitt Run Line", "Crossing B&O Survey", Line P1 No date |
| Related | 2507 | Hist Soc - HS-K00336 | Untitled, Washington Branch early survey with profile, "Hunter's Mill", "Grade Crossing W.O. & W. R.R" No date, "Snake Den Run" |
| Related | 2507 | Hist Soc - HS-K00337 | Untitled, Washington Branch early survey, profile, "Falls Church", "Ballston" No date |
| Related | 2507 | Hist Soc - HS-K00338 | Untitled, Washington Branch early survey, "Line A", Piney Branch, Vienna, VA No date |
| Related | 2507 | Hist Soc - HS-C04945 | Untitled, Washington Branch early survey, "East of Linden" in pencil No date |
| Related | 2507 | Hist Soc - HS-C04946 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-C04947 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-C04948 | Untitled, Washington Branch early survey, "Wapping Road" No date |
| Related | 2507 | Hist Soc - HS-C04949 | Untitled, Washington Branch early survey, Unnamed railroad shown No date |
| Related | 2507 | Hist Soc - HS-G01396 | Untitled, Washington Branch early survey No date |
| Related | 2507 | Hist Soc - HS-S00131 | Untitled, Washington Branch early survey, Pimmitt's Run Line, Line P1 No date, "B.& O. R.R. Location (?)" |
| Related | 2507 | Hist Soc - HS-S00132 | Untitled, Washington Branch early survey, Middleburg, Maxville Summit No date |
| Related | 2507 | Hist Soc - HS-R00062 | Untitled, Washington Branch early survey |
| Related | 2507 | Hist Soc - HS-R00063 | Untitled, Washington Branch early survey, Line F, Along Shenandoah River |
| Related | 2507 | Hist Soc - HS-U00659 | Untitled, Washington Branch early survey, "Snake Den Summit", |
| Related | 2507 | Hist Soc - HS-F02521 | Untitled, Washington Branch early survey |
| Related | 2507 | Hist Soc - HS-F02522 | Untitled, Washington Branch early survey, "Wapping Road to Front Royal" |
| Related | 2507 | Hist Soc - HS-F02523 | Untitled, Washington Branch early survey, "Richmond & Danville RR" |
| Related | 2507 | Hist Soc - HS-F02524 | Untitled, Washington Branch early survey, Line P1, "Washington and Alexandria Ry" |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Maryland&Washington |
