| Locator | Hist Soc - HS-E02100 | Type | Drawing | Doc Number | 510 | |
|---|---|---|---|---|---|---|
| Description | Proposed Extension of Shed Bristol with Passenger Arrangement | |||||
| Notes | Scale 1"=10' | |||||
| Date | 03/25/1881 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 38in x 19in (97cm x 49cm) |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| City | Bristol - VA |
| Structure | Station - Passenger |
| Structure | Station |
| Company | N&W RR - Norfolk & Western Railroad |
