| Locator | Hist Soc - HS-C04542 | Type | Drawing | Doc Number | 879 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Plat of Tract at Norfolk, Proposed to be Leased to The Norfolk Terminal Co | |||||
| Notes | Scale 1"=40', Coe book "Part of Pier No 2 on which is located the lumber shed; also the read of Pier No 1 on which is located Cotton Platform leased to Norfolk Terminal Company" | |||||
| Date | 09/06/1887 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 19in x 16in (48cm x 40cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Norfolk | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Pier | |
| Land | Lease |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Norfolk Terminal Co. | |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe | |
