| Locator | Hist Soc - HS-CC02284 | Type | Drawing | Doc Number | 1890 | |
|---|---|---|---|---|---|---|
| Description | Plan of Foundation for 32ft scale with Dead Rail | |||||
| Notes | Scale 1"=2'. Coe book "Foundation for 32-ft scale - Kenova" | |||||
| Date | 01/01/1892 | Revision Date | ||||
| Author | Accession | 2009.001 : NS Corp/Va Tech Collection | ||||
|
||
Size: 27in x 13in (70cm x 32cm) |
| Related | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Related | 1890 | Hist Soc - HS-CC02283 | Plan of Foundation for 32ft scale with Dead Rail Scale 1"=2' |
| Related | 1890 | Hist Soc - HS-A07645 | Bill of Timbers for 32 ft 60 ton track scale, Fairbanks Standard Scales |
| Related | 1890 | Hist Soc - HS-A07644 | Letter about foundation for 32' track scale Fairbanks Scale |
| City | Kenova - WV |
| Structure | Track - Scale |
| Company | N&W RR - Norfolk & Western Railroad |
