| Locator | Hist Soc - HS-C04347 | Type | Drawing | Doc Number | 535 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Segments of Cast Iron Arch for Big Tunnel, Clear Span of Arch 13ft at the Springing Line | |||||
| Date | 07/14/1886 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 22in x 17in (55cm x 42cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| City | Montgomery - VA |
| Structure | Tunnel |
| Company | N&W RR - Norfolk & Western Railroad |
