| Locator | Hist Soc - HS-C04329 | Type | Map | Doc Number | 2052 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Ohio Extension, Plan for Crossing of Poor Branch, Div. No 2 - Sec 125 Sta 1325 | |||||
| Notes | Scale 1"=4', Bridge #964 | |||||
| Date | 09/30/1890 | Revision Date | ||||
| Author | N&W RR - Office Div Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
|
|
Size: 17in x 15in (44cm x 39cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| Structure | Bridge |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Ohio Extension |
