| Locator | Hist Soc - HS-C04285 | Type | Drawing | Doc Number | 428 | |
|---|---|---|---|---|---|---|
| Description | Arch Culvert on Section 22, Cripple Creek Extn. | |||||
| Notes | "From Drawing by Walker" | |||||
| Date | 09/10/1884 | Revision Date | ||||
| Author | Accession | 2009.001 : NS Corp/Va Tech Collection | ||||
|
|
|
Size: 15in x 20in (38cm x 52cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| Structure | Culvert - Arch |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - Radford - Cripple Creek Extension |
