| Locator | Hist Soc - HS-H00801 | Type | Drawing | Doc Number | 385 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Coaling Station at Atkins Tank | |||||
| Notes | Scale 1"=4', No Date | |||||
| Date | Revision Date | |||||
| Author | Accession | 2009.001 : NS Corp/Va Tech Collection | ||||
|
||
Size: 44in x 28in (111cm x 72cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Child | 385 | Hist Soc - HS-B24117 | 20Lb Rail for Atkin's Coaling Station |
| Child | 385 | Hist Soc - HS-C04263 | Cross-Sections taken at Atkins's Tank, Sta. 0 = Eastern Head Block of switch (Ele. are take from bottom of tie) |
| Child | 385 | Hist Soc - HS-CC02128 | N&W RR, Atkins Coaling Station, Alteration to Bents 10 and 11 to allow for coaling engines on side track Scale 1"=4', No Date |
| Child | 385 | Hist Soc - HS-E02001 | Details & Framing for Coaling Station, Atkins, N&W RR No Date |
| City | Atkins - VA |
| Structure | Engine Service - Coaling |
| Structure | Station - Coaling |
| Company | N&W RR - Norfolk & Western Railroad |
