| Locator | Hist Soc - HS-CC02123 | Type | Drawing | Doc Number | 1757 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Lambert's Point Norfolk Va., Plan Showing Completed and Immediately Contemplated Improvements | |||||
| Notes | Scale 1"=200', "Approved by R. A. Dobis, Harbor Commissioner" | |||||
| Date | 02/23/1892 | Revision Date | 03/30/1892 | |||
| Author | Accession | 2009.001 : NS Corp/Va Tech Collection | ||||
|
|
|
Size: 26in x 16in (67cm x 40cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
| City | Lamberts Point - VA |
| Structure | Pier - Coal |
| Structure | Pier - Warehouse |
| Structure | Building - Warehouse |
| Company | N&W RR - Norfolk & Western Railroad |
