| Locator | Hist Soc - HS-C04129 | Type | Drawing | Doc Number | N-13730 | |
|---|---|---|---|---|---|---|
| Description | N&W Ry, Typical Design for Coal Trestle, Spans 15' Center to Center, I-Beam Stringers & Concrete Piers | |||||
| Notes | Scale 1"=4' | |||||
| Date | 04/22/1929 | Revision Date | 03/27/1936 | |||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
||
Size: 20in x 8in (52cm x 21cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Coal | Trestle |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | N-7500 | Hist Soc - HS-A08773 | Typical Design for Coal Trestle with I-Beam Stringers & Concrete Piers, spans 15'0" center to center. |
