| Locator | Hist Soc - HS-H10242 | Type | Drawing | Doc Number | 876 | |
|---|---|---|---|---|---|---|
| Description | Alternate Lines connecting the Eastern End of the New River Division with the Norfolk & Western Main Line | |||||
| Notes | Scale 1"=1000'. Four different proposals. Includes profiles. Line 3 was short wye connection at New River. Line 1 was close to eventual low-grade line via Cowan (with shorter tunnel |
|||||
| Date | 07/19/1887 | Revision Date | ||||
| Author | N&W Railroad | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 41in x 31in (104cm x 79cm) |
| Parent | Bound Volume - BV-E00001 | Copy, Index of Maps, W.W. Coe Incomplete index to early engineering drawings. Drawing numbers range from single digits into the high 2000s. Not all drawing numbers in that range listed. ~116 pages plus cover, several pages blank. |
|
| Child | Hist Soc - HS-E00741 | Alternate Lines Connecting the Eastern End of the New River Division with the Norfolk & Western Mainline Scale 1"=1000', Eastern End of the New River Division Schuler Hill |
| City | Radford - VA |
| City | Belspring - VA |
| City | New River - VA |
| Company | N&W RR - Norfolk & Western Railroad |
| Division | N&W RR - New River |
