| Locator | Hist Soc - HS-D02321 | Type | Drawing | Doc Number | 5287.3 | |
|---|---|---|---|---|---|---|
| Description | Batavia OH, Station - Foundation Plan | |||||
| Date | Revision Date | |||||
| Author | Cin, Portsm & Va RR | Accession | 2005.004 : Library of Virginia | |||
|
||
Size: 35in x 16in (90cm x 41cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Batavia | OH |
| Structures Indexes | |
|---|---|
| Category | Type |
| Station | |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| CP&V | Cincinnati Portsmouth & Virginia |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | 5287.4 | Hist Soc - HS-D02320 | Roof Framing for Station at Batavia OH |
| Related | 5287.3 | Hist Soc - HS-D02319 | Batavia OH station, Side View |
| Related | 5287.5 | Hist Soc - HS-C01276 | Batavia OH station, End View |
| Related | 5287.6 | Hist Soc - HS-C01275 | Batavia OH station, End View |
| Related | 5287.7 | Hist Soc - HS-C01274 | Batavia OH station, Section Throught Centre of Depot showing proposed arrangement |
| Related | 5287.8 | Hist Soc - HS-C01273 | End View, Batavia OH station. |
| Related | 5287.2 | Hist Soc - HS-D02322 | Batavia OH, Station - Side Elevation |
| Related | 5287.1 | Hist Soc - HS-D02323 | Batavia OH, Station - Side Elevation |
