| Locator | Hist Soc - HS-E10155 | Type | Map | Doc Number | 11664-J | |
|---|---|---|---|---|---|---|
| Description | Map Showing Lines of N&W, C&O and VGN in the Vicinity of Gilbert, W.Va. and Proposed Extensions to serve US Coal and Coke Co. | |||||
| Notes | Scale 1"=3000' Never constructed |
|||||
| Date | 06/17/1948 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 36in x 29in (92cm x 73cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Devon | WV |
| Gilbert | WV |
| Justice | WV |
| Thacker | WV |
| Delorme | WV |
| Wharncliffe | WV |
| Matewan | WV |
| Cedar | WV |
| War Eagle | WV |
| Glen Alum | WV |
| McCarr | WV |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | |
| Track | Siding |
| Track | Mine |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| C&O | Chesapeake & Ohio |
| N&W Rwy | Norfolk & Western Railway |
| VGN Rwy | Virginian Railway |
| USC&C | United States Coal & Coke Co. |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W Rwy | Pocahontas | ||
| VGN Rwy | New River | Guyandot River Br | |
| N&W Rwy | Pocahontas | Gilbert Branch | |
| N&W Rwy | Pocahontas | Various Branches | |
