| Locator | NW Mech Dwg - NW-D07171 | Type | Drawing | Doc Number | D7171 | |
|---|---|---|---|---|---|---|
| Description | Drawbar Connection Between Engine and Tender Details, Loco. Class B, W, A, V | |||||
| Date | 10/21/1904 | Revision Date | 08/05/1927 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
||
Size: 32in x 22in (82cm x 56cm) |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Baldwin - A - 4-6-0 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Baldwin - B - 2-8-0 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - V - 4-6-0 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - W - 2-8-0 |
