| Locator | NW Mech Dwg - NW-C38284 | Type | Drawing | Doc Number | C38284 | |
|---|---|---|---|---|---|---|
| Description | Frame Section. Between Int. and Main Wheels, L.P. Engine, Loco. Class Y3, Y3a (Style No. 1) | |||||
| Date | 03/10/1942 | Revision Date | 05/25/1942 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
||
Size: 24in x 16in (60cm x 41cm) |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3 - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3a - 2-8-8-2 |
