Locator NW Mech Dwg - NW-D35902 Type Drawing Doc Number D35902
Description Arrangement and Details of Muffler for Okadee Blow-off Valve. Class Y5 (Engs. 2114 + 2118), Y6, Y6a, Y6b
Date 10/19/1938 Revision Date 11/26/1954
Author N&W Rwy - Motive Power Accession 2001.001 : Mark Faville

Arrangement and Details of Muffler for Okadee Blow-off Valve. Class Y5 (Engs. 2114 + 2118), Y6, Y6a, Y6b

Size: 33in x 23in (84cm x 59cm)

Rolling Stock N&W Rwy - Locomotive - Steam - Roanoke Shops - Y5 - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Roanoke Shops - Y6 - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Roanoke Shops - Y6a - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Roanoke Shops - Y6b - 2-8-8-2
