| Locator | Hist Soc - HS-A08812 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Table of Distances from Point of Switch to 14' Clearance for various types of commercial sidings | |||||
| Notes | Sheet 106-A. | |||||
| Date | 07/01/1934 | Revision Date | 04/01/1940 | |||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
|
|
Size: 9in x 6in (22cm x 15cm) |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Related | N-7500 | Hist Soc - HS-A08811 | Table of Distances from Point of Switch to 13' Clearance for various types of commercial sidings Sheet 106. |
| Structure | Track - Switch |
| Structure | Track - Siding |
| Company | N&W Rwy - Norfolk & Western Railway |
