| Locator | Hist Soc - HS-B24927 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | No. 8 Ladder Angle with No. 10 Turnouts | |||||
| Notes | Sheet 88. |
|||||
| Date | Revision Date | |||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
||
Size: 14in x 6in (36cm x 15cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Switch |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 |
