| Locator | Hist Soc - HS-A08820 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Weights per Span A.R.E.A. 1923 E70 | |||||
| Notes | Sheet 125. Truss Spans, Plate Girder Spans, and Thru-Deck. | |||||
| Date | 11/10/1931 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
|
|
Size: 7in x 10in (17cm x 25cm) |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Related | N-7500 | Hist Soc - HS-A08819 | Weights per Span A.R.E.A. 1923 E60 Sheet 124. Truss Spans, Plate Girder Spans, and Thru-Deck. |
| Structure | Bridge |
| Company | N&W Rwy - Norfolk & Western Railway |
