| Locator | Hist Soc - HS-B24950 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Typical Double Connected Coal Operation Siding Layout | |||||
| Notes | Sheet 119. | |||||
| Date | 01/01/1933 | Revision Date | 03/27/1936 | |||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
||
Size: 14in x 6in (36cm x 15cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Siding |
| Coal | Tipple |
| Track | Tipple |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 |
| Related | N-7500 | Hist Soc - HS-B24951 | Typical Single Connected Coal Operation Siding Layout |
