| Locator | Hist Soc - HS-A08774 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | 115' Turntable - Estimated Cost. | |||||
| Notes | Sheet 65. Tables for THru Truss type Y8877 and Deck Girder type Y8935. | |||||
| Date | 09/05/1924 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
|
|
Size: 10in x 7in (25cm x 17cm) |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Structure | Turntable |
| Company Docs | N&W Rwy - Cost Estimation Tables |
