| Locator | Hist Soc - HS-A08770 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Estimating Table, Approach Trestle L-71 to Standard Coal Trestle | |||||
| Notes | Sheet 50. Typical estimate of cost | |||||
| Date | Revision Date | 06/19/1930 | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
|
|
Size: 6in x 9in (16cm x 24cm) |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Related | N-7500 | Hist Soc - HS-A08771 | Estimating Table, Coal Trestle Type Y-1950 Sheet 51. Typical estimate of cost |
| Related | N-7500 | Hist Soc - HS-A08772 | Estimating Table, Coal Trestle ~ Concrete Piers and Wood Stringer Type Y-1950 Sheet 52. Typical estimate of cost |
| Related | N-7500 | Hist Soc - HS-A08768 | Estimating Table, Standard Coal Trestle L-251 Sheet 48. Typical estimate of cost |
| Related | N-7500 | Hist Soc - HS-A08769 | Estimating Table, Coal Trestle Standard Deck L-251, Concrete Piers Sheet 49. Typical estimate of cost |
| Structure | Coal - Trestle |
| Company Docs | N&W Rwy - Cost Estimation Tables |
