| Locator | Hist Soc - HS-A08761 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Sidings for Handling Infamable Liquids, for use with 131lb and 132lb rail | |||||
| Notes | Sheet 34-C. Typical estimate of cost | |||||
| Date | 03/01/1966 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2005.004 : Library of Virginia | |||
|
||
Size: 9in x 6in (23cm x 15cm) |
| Related | N-7500 | Hist Soc - HS-A08760 | Sidings for Handling Infamable Liquids, for use with 100lb rail Sheet 34-B. Typical estimate of cost |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Structure | Track - Siding |
| Company Docs | N&W Rwy - Cost Estimation Tables |
| Company | N&W Rwy - Norfolk & Western Railway |
