| Locator | Hist Soc - HS-E02150 | Type | Drawing | Doc Number | 1711 | |
|---|---|---|---|---|---|---|
| Description | N&W RR, Ohio Extension, Siding to Proposed Mines on May Branch | |||||
| Notes | Scale 1"=50' | |||||
| Date | 12/31/1891 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 41in x 19in (105cm x 49cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Siding |
| Track | Mine |
| Coal | Tipple |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W RR | Ohio Extension | Dingess Branch | |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Parent | 1711 | Hist Soc - HS-D05197 | N&W RR, Ohio Extension, Siding to Proposed Mines on Mays Branch |
